SPECIFICATION

1,Working Medium:Air source

2,Body material:Zinc die-casting

3,Filter bowl and Lubricator bowl material:PC

4,Filter element material:Brass

5,Bowl Guard:Aluminum alloy

6,Seal Material:NBR

7,Adjustabing knob:POM

8,Working pressure:0.5~12Bar or 0.5~7Bar

9,Working Temperature:0~60℃

10,Filtration fineness:5µ or 40µ

11,Mounting type: Pipe mounting or bracket support mounting

12,Regulator type:Diaphragm type or piston type

13,Lubricator type:Oil volume adjustable during working

14,Port size:G1/8”~G1”

15,Drainage model:Manual drainer,Semi-automatic drainer,automatic drainer

16,Deisgn type:Modular
